New Norgren 2/2 Direct Solenoid Actuated Poppet Valve 2102500

Solenoids group A, standard voltages Power consumption 24 V d.c. 230 V a.c. (W) (VA) Rated current 24 V d.c. 230 V a.c. (m A) (m A) Protection class IP/NEMA Ex-Protection (ATEX-Category) Temperature Ambient/ Media (°C) Electrical connection Weight (kg) Drawing No. Circuit diagram No. Model 13,6 — 567 — 4x Cl. I, Div. 1, Gr. A - D Cl. II/III, Div. 1, Gr. E - G T3C (160°C)-20 ... +60 Flying leads length 460 mm 0,5 8 1 3826 — 15,7 — 68 4x Cl. I, Div. 1, Gr. A - D Cl. II/III, Div. 1, Gr. E - G T3C (160°C)-20 ... +60 Flying leads length 460 mm 0,5 8 5 3827 Standard voltages (±10%) 24 V d.c., 230 V a.c., other voltages on request. Design according to VDE 0580, EN 50014/50028. 100% duty cycle. *1) Connector/cable gland is not scope of delivery, see table »Accessories« Attention: The protection class for coil series 46xx and 48xx is determined by the choice of cable gland. Example: if an ATEX-certified cable gland is used that has Ex d type of protection, the solenoid will have the protection class Ex d mb; if a cable gland with Ex e type of protection is used, the solenoid will have protection class Ex e mb. Cable gland Protection class Ex e, Ex d (ATEX), Nickel plated brass/ Stainless steel Page 6 Material Protection class (ATEX) Ambient temperatur limitation *1) Model For solenoid Thread Cable ø (mm) 42xx M20 x 1,5 7,0 … 12,0 Plastic II 2G Ex e / II 2D Ex t See table 0589735 42xx M20 x 1,5 10,0 … 14,0 Plastic II 2G Ex e / II 2D Ex t See table 0589736 42xx M20 x 1,5 6,0 … 12,0 Plastic II 2G Ex e / II 2D Ex t See table 0589737 42xx M20 x 1,5 5,0 … 10,0 Plastic II 2G Ex e / II 2D Ex t See table 0589739 46xx M20 x 1,5 5,0 … 8,0 Nickel plated brass II 2G Ex e / II 2D Ex t-0588819 46xx M20 x 1,5 10,0 … 14,0 Nickel plated brass II 2G Ex d / II 2D Ex t-0588851 46xx 1/2 NPT 7,5 … 11,9 Nickel plated brass II 2G Ex d / II 2D Ex t-0588925 46xx, 48xx M20 x 1,5 9,0 … 13,0 Stainless steel 1.4571 II 2G Ex e / II 2D Ex t-0589385 46xx, 48xx M20 x 1,5 7,0 … 12,0 Stainless steel 1.4404 II 2G Ex d / II 2D Ex t-0589395 46xx, 48xx M20 x 1,5 10,0 … 14,0 Stainless steel 1.4404 II 2G Ex d / II 2D Ex t-058938
