Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States

Place of Origin USA
اسم العلامة التجارية Dwyer
إصدار الشهادات -
Model Number 2000 Series Magnehelic
Minimum Order Quantity 1
الأسعار USD35/PC
Packaging Details Original
Delivery Time in stock
Payment Terms L/C, D/A, D/P, T/T, MoneyGram, Western Union
Supply Ability 1000

اتصل بي للحصول على عينات مجانية وكوبونات.

ال WhatsApp:0086 18588475571

WeChat: 0086 18588475571

سكايب: sales10@aixton.com

إذا كان لديك أي قلق ، فنحن نقدم مساعدة عبر الإنترنت على مدار 24 ساعة.

x
تفاصيل المنتج
Weight (kg) 0.55KG brand name Dwyer
Usage Igniting Product name 2000-3Kpa
اترك رسالة
منتوج وصف
Product Overview
  • Accuracy Detail

    ± 2% (-HA model ± 1) of FS (± 3% (-HA ± 1.5%) on -0, -100PA, -125PA, -10MM and ± 4% (-HA ± 2%) on -00, -60PA, -6MM ranges), throughout range at 70°F (21.1°C).

  • Dial Dia4 in
  • Enclosure RatingsIP67
  • MaterialsAluminum, Acrylic
  • Materials, WettedConsult Factory
  • Media CompatibilityAir, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
  • Mounting OrientationVertical Diaphragm
  • Pressure Limits-20 inHg to 15 psig
  • Measurement Pressure TypeDifferential
  • Process Connection Note1/8˝ female NPT duplicate high and low pressure taps - one pair side and one pair back.
  • Process Connection Size1/8 in
  • Process Connection TypeNPT Female
  • Safety FeaturesRelief plug opens at approximately 25 psig (1.72 bar), standard gages only.
  • Weight510 gDwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 0Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 1Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 2Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 3Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 4Dwyer 2000 Series Magnehelic Differential Pressure Gauge 0-3KPa From the United States 5
